From: £40.00 excl. VAT
Fire Rating – 1 Hour
Frame – 25mm Beaded Frame Detail
Lock Type – Budget lock as standard
Finish – RAL 9010 30% gloss
Fitting Method – FlipFix Fitting Device (more information)
“The FlipFix range is 6 times faster to fit than a traditional access panel. The unique fitting device is designed to clamp to boards with a depth between 8-32mm.
This panel is constructed from 0.9mm zintec steel with a plasterboard-faced panel. This panel is certified to BS EN 1634-1 : 2014 for a 1 hour integrity fire rating.
There is no longer the need to brace or support the structural opening, and no extra screws or glue required. You simply follow the fitting instructions, lock the door and walk away.
The beaded frame allows a wet finish to be applied (plaster), allowing for a completely concealed installation, the only thing visible will be the lock cap.
Acoustic Rating | None |
---|---|
Airtight Rated | No |
Anti-Ligature | No |
Door Type | Access Panel |
Fire Rating | 1 Hour |
Fitting Style | FlipFix Fitting System |
Frame Type | Beaded |
Insulated | No |
Orientation | Ceilings, Walls |
Panel Face | Plasterboard |
Smoke Tested | No |
Size | 150 x 150mm, 200 x 200mm, 300 x 300mm, 450 x 450mm, 550 x 550mm, 600 x 300mm, 600 x 600mm |
Suitable Locks | 5mm Bit, Budget Lock, Castellated Key Lock, Flush Lock, Key Retaining Lock, Touch Catch |
Availability | Show Stock Only |
To fit the panel, cut the plasterboard to the structural opening size required ensuring the aperture is 5mm larger than the panel size.
Place your frame into the aperture, no need to remove the door from the frame. Set your drill to a low torque setting before the next step.
Proceed to screw the FlipFix device in place until it grips on to the rear of the plasterboard securely.
Lock the door in place with key provided & ensure the door is flush when closed. You have successfully installed a FlipFix Access Panel!
